SC-LC UPC Duplex Adapter in Kenya
KSh 50.00
1 available
Continue shoppingSC-LC UPC Duplex Adapter in Kenya
The SC-LC UPC Duplex Adapter is a hybrid fibre optic adapter designed to connect SC/UPC and LC/UPC fibre interfaces within the same optical link. Unlike a standard SC-SC or LC-LC adapter, this hybrid coupler provides a convenient transition between two different connector formats, helping technicians connect existing SC-based fibre infrastructure to compact LC-based networking equipment without unnecessarily replacing patch cords or termination hardware.
A duplex SC-LC hybrid adapter supports two optical fibre channels, making it suitable for conventional transmit-and-receive Ethernet links. Current LC-to-SC hybrid adapters use precision alignment components to maintain accurate fibre positioning while minimizing connection loss. FS currently lists an LC-to-SC SM/MM duplex fibre optic adapter specifically designed for precision interconnection between different fibre connector types.
At Fiber Optics Kenya, the SC-LC UPC Duplex Adapter is suitable for enterprise LANs, data centres, ODFs, fibre patch panels, server rooms, telecommunications networks and fibre upgrade projects. Customers can also source compatible SC/UPC patch cords, LC/UPC patch cords, SC-LC hybrid patch cords, pigtails, SFP modules, ODFs and fibre cleaning accessories.
Key Product Specifications
| Specification | Details |
|---|---|
| Product Name | SC-LC UPC Duplex Adapter |
| Product Type | Hybrid Fibre Optic Adapter / Coupler |
| Connector Interface A | SC/UPC |
| Connector Interface B | LC/UPC |
| Configuration | Duplex |
| Number of Fibre Channels | 2 |
| Polish Type | UPC |
| Typical Housing Colour | Blue |
| Fibre Compatibility | Single Mode / Multimode depending on model |
| Common Single-Mode Category | OS2 |
| Common Multimode Categories | OM1 / OM2 / OM3 / OM4 |
| Alignment Sleeve | Zirconia Ceramic commonly |
| Typical Insertion Loss | ≤0.2 dB on representative hybrid adapters |
| Typical Return Loss | >50 dB on representative UPC models |
| Mounting Style | Panel / Hybrid adapter |
| Housing Material | Plastic or metal depending on model |
| Primary Applications | ODF, patch panel, LAN, SFP, telecom |
| Installation Environment | Indoor / protected enclosure |
| Professional Installation | Available |
| Delivery | Available throughout Kenya |
A current LC-SC duplex hybrid adapter specifies a high-precision zirconia ceramic alignment sleeve and ≤0.2 dB insertion loss, while another LC-SC duplex design specifies insertion loss ≤0.2 dB and return loss above 50 dB.
What Is an SC-LC UPC Duplex Adapter?
An SC-LC adapter provides a physical transition between two different fibre connector formats.
| Feature | Description |
|---|---|
| SC Side | Accepts compatible SC/UPC interface |
| LC Side | Accepts compatible LC/UPC interface |
| Connector Combination | Hybrid |
| Number of Channels | 2 |
| Optical Conversion | None |
| Electrical Conversion | None |
| Main Function | Align and connect different connector formats |
| Typical Use | Existing SC infrastructure to LC equipment |
The adapter does not convert wavelengths, fibre modes or network speeds. It simply provides mechanical and optical alignment between compatible connectors.
What Does SC-LC UPC Duplex Mean?
| Term | Meaning |
|---|---|
| SC | Standard / Subscriber Connector |
| LC | Small-form-factor fibre connector |
| UPC | Ultra Physical Contact |
| SC-LC | Hybrid connection between SC and LC formats |
| Duplex | Two fibre channels |
| Adapter | Passive connector-alignment component |
| Hybrid Adapter | Connects two different connector formats |
SC vs LC Connector
The main purpose of the adapter becomes clearer when comparing SC and LC connectors.
| Feature | SC | LC |
|---|---|---|
| Connector Size | Larger | Smaller |
| Ferrule Diameter | Approx. 2.5 mm | Approx. 1.25 mm |
| Connection Style | Push-Pull | Latching |
| ODF Use | Very Common | Common |
| Patch Panel Use | Excellent | Excellent |
| SFP Module Use | Less Common | Very Common |
| High-Density Networking | Moderate | Excellent |
| Legacy Fibre Infrastructure | Very Common | Common |
| Modern Data Centres | Good | Excellent |
LC connectors are compact and therefore widely used in high-density network equipment, while SC remains common in existing ODFs and fibre distribution systems.
Why Use a Hybrid SC-LC Adapter?
A hybrid adapter is particularly useful when a network already contains two different connector types.
| Network Situation | Benefit |
|---|---|
| SC ODF + LC Equipment | Avoid replacing existing ODF |
| SC Patch Cord + LC Interface | Provides connector transition |
| Legacy SC Infrastructure | Easier integration with newer equipment |
| High-Density LC Equipment | Connects to existing SC fibre |
| Network Upgrades | Reduces unnecessary recabling |
| Testing Equipment | Allows mixed connector interfaces |
| Temporary Fibre Links | Convenient connector adaptation |
FS describes the LC-SC hybrid adapter specifically as an adapter designed for the precision connection of different types of fibre optic connectors.
Duplex Fibre Connectivity
A duplex adapter handles two fibre channels.
| Fibre Channel | Typical Function |
|---|---|
| Channel A | Transmit |
| Channel B | Receive |
| Duplex Feature | Benefit |
|---|---|
| 2 Fibre Paths | Conventional bidirectional Ethernet |
| Compact Housing | Saves panel space |
| LC Duplex Interface | Suitable for high-density networks |
| SC Interface | Integrates existing infrastructure |
| Single Adapter Assembly | Simplifies mixed-connector installation |
Corning's current fibre portfolio includes LC duplex and SC duplex UPC adapters, demonstrating the widespread use of duplex connectivity on both connector platforms.
Typical Optical Performance
| Optical Parameter | Typical / Representative Value |
|---|---|
| Connector Types | SC/UPC and LC/UPC |
| Configuration | Duplex |
| Insertion Loss | ≤0.2 dB on representative products |
| Return Loss | >50 dB on representative UPC hybrid products |
| Alignment Sleeve | Zirconia Ceramic |
| Single-Mode Compatibility | Yes on appropriate model |
| Multimode Compatibility | Yes on appropriate model |
| Optical Signal Conversion | None |
| Network Speed Limitation | Primarily determined by fibre and optics |
One commercially available metal LC-to-SC duplex hybrid adapter specifies ≤0.2 dB insertion loss, >50 dB return loss and ceramic alignment sleeves.
Typical Mechanical Characteristics
| Parameter | Typical Description |
|---|---|
| Adapter Configuration | Duplex |
| Connector Combination | LC-SC |
| Housing Colour | Blue commonly for UPC |
| Housing Material | Engineering plastic / metal |
| Alignment Sleeve | Zirconia ceramic commonly |
| Panel Mounting | Model dependent |
| Dust Protection | Dust caps commonly supplied |
| Operating Temperature | Model dependent |
| Mating Durability | Product dependent |
| Installation Environment | Indoor / enclosure |
A representative LC-SC hybrid adapter operates between approximately -25°C and +70°C, while another metal version lists operation from -40°C to +75°C.
Why Ceramic Alignment Sleeves Matter
| Advantage | Benefit |
|---|---|
| High Precision | Keeps fibre cores accurately aligned |
| Low Wear | Stable repeated connections |
| Low Optical Loss | Protects optical power budget |
| Temperature Stability | Reliable performance |
| Single-Mode Suitability | Excellent |
| Long Service Life | Better durability |
Corning also uses ceramic inserts in its single-mode SC duplex UPC adapter systems, reinforcing ceramic alignment as a standard approach for precision single-mode connections.
SC-LC Hybrid Adapter vs SC-LC Patch Cord
| Feature | SC-LC Adapter | SC-LC Patch Cord |
|---|---|---|
| Function | Couples existing connectors | Provides complete fibre cable link |
| Contains Fibre Cable | No | Yes |
| Installed in Panel | Common | No |
| Connector Conversion | At coupling point | At cable ends |
| Existing Patch Cords Reused | Often Yes | Not necessary |
| Best Use | Mixed connector infrastructure | Direct device-to-device link |
A hybrid adapter is useful when you want to retain existing cables, while an SC-LC patch cord is often simpler where a new cable can be installed.
SC-LC Adapter vs SC-SC Adapter
| Feature | SC-LC Hybrid | SC-SC |
|---|---|---|
| Connector Types | Different | Same |
| SC Side | Yes | Yes |
| LC Side | Yes | No |
| Hybrid Connection | Yes | No |
| SC-to-SC Network | Not necessary | Excellent |
| SC-to-LC Network | Excellent | Requires another solution |
SC-LC Adapter vs LC-LC Adapter
| Feature | SC-LC | LC-LC |
|---|---|---|
| Connector Combination | Hybrid | Same connector |
| LC Equipment Connection | Yes | Yes |
| SC Infrastructure Connection | Yes | No |
| High-Density LC Panels | Useful | Excellent |
| Legacy SC Integration | Excellent | Requires conversion |
Corning produces LC duplex adapters compatible with OM1, OM2, OM3, OM4 and OS2, showing that LC adapter technology itself is widely used across both multimode and single-mode systems.
UPC vs APC Hybrid Adapter
| Feature | UPC | APC |
|---|---|---|
| Typical Colour | Blue | Green |
| Polish Type | Ultra Physical Contact | Angled Physical Contact |
| General Ethernet | Very Common | Less Common |
| FTTH / PON | Equipment dependent | Very Common |
| Back Reflection | Low | Lower |
| Can UPC Mate Directly to APC? | No | No |
Do not connect an APC connector to a UPC interface simply because the connector body fits. The polished end faces are different.
Single Mode vs Multimode SC-LC Adapter
| Feature | Single Mode | Multimode |
|---|---|---|
| Typical Fibre Category | OS2 | OM1 / OM2 / OM3 / OM4 |
| Common UPC Housing | Blue | Varies by fibre grade |
| Long-Distance Networks | Excellent | More Limited |
| Data Centre Short Reach | Excellent | Excellent |
| Telecommunications | Excellent | Application dependent |
| Multimode SFP Compatibility | No | Yes |
| Single-Mode SFP Compatibility | Yes | No |
FS currently describes its LC-SC hybrid duplex adapter as suitable for SM/MM fibre connections, but the actual fibre and optics on each side must remain compatible.
Watch SC-LC UPC Duplex Adapter
Watch on YouTube: https://youtu.be/x8xfV0qnOBk
The SC-LC UPC Duplex Adapter provides a practical solution when a fibre installation uses SC connectors on one side and LC connectors on the other. Instead of replacing existing fibre infrastructure, a hybrid adapter allows technicians to integrate the different connector formats while maintaining precise fibre alignment. Current LC-SC duplex hybrid adapters use precision ceramic alignment components and are designed specifically for mixed-connector optical links.
The duplex design provides two optical channels, making it particularly useful for conventional Ethernet connections that require separate transmit and receive fibres. This makes the adapter suitable for connecting older SC-based ODFs and patch panels to modern LC-equipped switches, transceivers and network equipment. LC connectors are also especially useful where high port density is required, while SC remains widely deployed in existing fibre distribution systems.
For best optical performance, connector cleanliness and fibre compatibility remain important. The adapter changes only the connector interface; it does not convert single-mode fibre to multimode or compensate for incompatible transceivers. Fiber Optics Kenya can supply the SC-LC UPC Duplex Adapter together with SC and LC patch cords, pigtails, fibre cleaners, ODFs, patch panels and SFP modules, helping customers build complete hybrid fibre connectivity solutions.
Applications of SC-LC UPC Duplex Adapter
1. SC ODF to LC Equipment
Integrate existing SC fibre distribution with LC-based active equipment.
2. Network Switches
Connect SC infrastructure to LC-equipped optical modules.
3. SFP and SFP+ Networks
Provide connector-format adaptation where appropriate patching is required.
4. Fibre Patch Panels
Create hybrid connection points in mixed SC and LC fibre environments.
5. Data Centres
Integrate existing SC cabling with higher-density LC network infrastructure.
6. Enterprise LANs
Support mixed connector types during network upgrades.
7. Telecommunications Networks
Connect compatible SC and LC single-mode infrastructure.
8. CCTV Fibre Networks
Adapt mixed fibre interfaces in compatible optical CCTV equipment.
9. Fibre Testing
Connect test leads with different connector formats.
10. Network Migration Projects
Retain existing SC infrastructure while introducing LC-equipped hardware.
Typical Hybrid Network Connection
| Network Component | Interface |
|---|---|
| Existing Fibre Patch Cord | SC/UPC Duplex |
| Hybrid Adapter Side A | SC/UPC |
| Hybrid Adapter Side B | LC/UPC |
| LC Fibre Connection | LC Duplex |
| Optical Equipment | Switch / SFP / Network Device |
Recommended Accessories
| Accessory | Purpose |
|---|---|
| SC/UPC Patch Cord | Connects SC equipment |
| LC/UPC Patch Cord | Connects LC equipment |
| SC-LC Patch Cord | Direct hybrid fibre connection |
| SC/UPC Pigtail | SC fibre termination |
| LC/UPC Pigtail | LC fibre termination |
| SC Fibre ODF | Fibre distribution |
| LC Patch Panel | High-density fibre termination |
| Single-Mode SFP Module | Optical network interface |
| Multimode SFP Module | Multimode optical connectivity |
| Fibre Connector Cleaner | Keeps interfaces clean |
| Optical Power Meter | Measures optical signal |
| Visual Fault Locator | Helps trace fibre faults |
| OTDR | Tests complete fibre links |
Why Buy SC-LC UPC Duplex Adapter from Fiber Optics Kenya?
| Why Choose Fiber Optics Kenya? | Customer Benefit |
|---|---|
| Hybrid SC-LC Adapters | Connect different connector formats |
| Duplex Options | Supports two-fibre Ethernet links |
| UPC Connectivity | Suitable for compatible fibre networks |
| Single & Multimode Solutions | Options for different projects |
| SC & LC Patch Cords | Matching fibre cables available |
| SC & LC Pigtails | Complete termination solutions |
| ODFs & Patch Panels | Complete distribution infrastructure |
| SFP Modules | Active optical networking solutions |
| Technical Guidance | Help match fibre modes and interfaces |
| Bulk Supply | Suitable for contractors and ISPs |
| Competitive Pricing | Cost-effective project procurement |
| Nationwide Delivery | Supply throughout Kenya |
Frequently Asked Questions
What is an SC-LC UPC Duplex Adapter?
It is a hybrid fibre optic adapter designed to connect compatible SC/UPC and LC/UPC fibre interfaces while supporting two fibre channels. FS currently lists LC-SC hybrid duplex fibre adapters for this purpose.
Why is it called a hybrid adapter?
It connects two different connector formats rather than two identical connectors.
What does duplex mean?
Duplex means the adapter supports two optical fibre channels, commonly used as transmit and receive paths.
What does UPC mean?
UPC means Ultra Physical Contact, referring to the connector ferrule polish.
What colour is a UPC adapter?
Single-mode UPC interfaces are commonly identified with blue housings. Corning's SC Duplex UPC OS2 adapter panels use blue housings.
Can it connect SC to LC?
Yes. That is the primary purpose of an SC-LC hybrid adapter.
What is the typical insertion loss?
Representative LC-SC hybrid duplex adapters specify insertion loss of approximately ≤0.2 dB.
What type of alignment sleeve is used?
Quality versions commonly use zirconia ceramic alignment sleeves.
Can it be used with single-mode fibre?
Yes. Single-mode LC-SC hybrid adapters are commercially available.
Can it be used with multimode fibre?
Yes, appropriate multimode variants are also available. FS identifies its LC-SC hybrid duplex adapter as suitable for SM/MM applications.
Does the adapter convert single mode to multimode?
No. It only adapts the connector format. Fibre mode must remain compatible across the link.
Can it connect an SC ODF to an LC SFP?
It can form part of that connection where the fibre mode, connector polish and transceivers are all compatible.
Is LC commonly used with SFP modules?
Yes. LC duplex connectors are widely used with optical transceivers and modern network equipment.
Is SC commonly used in ODFs?
Yes. SC remains widely used in fibre distribution and patch-panel infrastructure.
Can SC/UPC be connected to LC/APC through this adapter?
No. UPC and APC connector polishes should not be mixed.
Can I use an SC/APC patch cord with this adapter?
Not if the adapter is specified for UPC interfaces. Use matching UPC connectors.
Is the adapter active equipment?
No. It is a completely passive optical component.
Does it need electrical power?
No.
Does it change the wavelength?
No. The adapter only aligns connectors.
Does it affect network speed?
A properly specified adapter does not determine Ethernet speed. Network speed depends primarily on fibre type, optics and link design.
Can it be mounted in a patch panel?
Yes, depending on the adapter's mounting design and panel cutout.
Can it be used in a data centre?
Yes. Hybrid adapters are useful where different connector formats must be integrated.
Is cleaning important?
Yes. Dirty connector ferrules can increase insertion loss and cause unreliable optical performance.
Do you supply SC and LC patch cords?
Yes. Fiber Optics Kenya can supply compatible SC, LC and SC-LC fibre patch cords.
Do you supply SC and LC pigtails?
Yes. Matching fibre pigtails and termination accessories can be supplied.
Do you supply SFP modules?
Yes. Compatible optical transceivers can be supplied according to network speed, fibre mode and distance requirements.
Do you provide fibre installation and testing?
Yes. Professional fibre termination, installation and testing support is available.
Do you deliver outside Nairobi?
Yes. Fiber Optics Kenya supplies fibre optic products and accessories throughout Kenya.
Contact Fiber Optics Kenya
Fiber Optics Kenya
Lyric House
7th Floor Room S9
Kimathi Street
Nairobi
Phone: +254 704 991 492
Email: info@fibreopticskenya.co.ke
The SC-LC UPC Duplex Adapter provides a practical way to integrate SC-based fibre infrastructure with LC-equipped network devices while maintaining reliable duplex optical connectivity.
Contact Fiber Optics Kenya for competitive pricing, SC-LC hybrid adapters, matching fibre accessories, bulk orders and nationwide delivery across Kenya.
