EPON OLT SFP PX20+++ 7dB Price in Kenya

The EPON OLT SFP PX20+++ 7dB is a high-power PON optical transceiver designed specifically for the PON port of an EPON Optical Line Terminal (OLT).

It provides the optical interface between the OLT and the passive optical distribution network connecting multiple EPON ONUs or ONTs.

A typical PX20+++ module supports 1.25Gbps EPON transmission, up to 20km over single-mode fibre, 1490nm downstream transmission and 1310nm burst-mode upstream reception. It uses a single-fibre BiDi optical interface, commonly with an SC connector.

This module should not be confused with an ordinary 1G Ethernet SFP. Although both use an SFP form factor, the PX20+++ is designed specifically for EPON OLT PON applications.

EPON OLT SFP PX20+++ 7dB Specifications

Manufacturer specifications consistently identify the PX20+++ class as 1.25G, Tx1490nm/Rx1310nm, 20km and ≥7dB, although exact optical characteristics vary between brands.

What Is an EPON OLT SFP Module?

An EPON OLT SFP is the optical transceiver installed in an EPON OLT's PON interface.

It converts the OLT's electrical data into optical signals for transmission through the passive optical network and receives upstream optical signals transmitted by subscriber ONUs.

A basic network looks like:

Internet → Router → EPON OLT → PX20+++ SFP → ODF → Feeder Fibre → PLC Splitter → Distribution Fibre → ONU → Customer Router

The module therefore forms a critical optical interface between the active OLT and the passive fibre network.

What Does EPON Mean?

EPON stands for:

Ethernet Passive Optical Network

It uses Ethernet technology to deliver broadband services over a passive optical distribution network.

What Does PX20+++ Mean?

PX20 identifies an EPON optical power/reach class, while manufacturers commonly use additional + designations to differentiate higher-output module variants.

A current manufacturer family provides:

Another EPON transceiver manufacturer similarly specifies PX20+ at 3–5dB, PX20++ at 5–7dB and PX20+++ at ≥7dB.

Because naming conventions can vary between suppliers, always verify the actual datasheet rather than relying only on the number of plus signs.

7dB EPON OLT SFP

The 7dB PX20+++ is designed to provide stronger optical output than lower-class PX20+ and PX20++ modules.

This can be useful in networks containing:

• Longer fibre routes

• Larger splitter ratios

• Multiple connectors

• Several fusion splices

• Distribution boxes

• Patch panels

• Additional optical losses

However, a higher-power module does not eliminate the need to calculate the complete optical budget.

1.25Gbps EPON Transmission

The PX20+++ supports a typical serial optical interface of:

1.25Gbps

and complies with IEEE 802.3ah EPON specifications.

This is suitable for standard GEPON/EPON access networks.

20KM Transmission Distance

A typical PX20+++ module supports fibre transmission distances of up to:

20 kilometres

over suitable single-mode fibre.

The actual achievable distance depends on the complete optical distribution network rather than fibre length alone.

Factors include:

Fibre Loss + Splitter Loss + Connector Loss + Splice Loss + Engineering Margin

1490nm Downstream Wavelength

The OLT module transmits downstream data at approximately:

1490nm

The signal travels:

OLT → ONU

This carries downstream traffic toward subscribers.

1310nm Upstream Wavelength

Subscriber ONUs typically transmit upstream toward the OLT at:

1310nm

The PX20+++ therefore contains a burst-mode receiver designed to detect 1310nm upstream signals from multiple ONUs.

Manufacturer specifications identify the module as using a 1490nm DFB transmitter and 1310nm APD burst receiver.

Single-Fibre BiDi Operation

EPON uses bidirectional transmission over one fibre strand.

The same fibre carries:

1490nm ↓ Downstream

and

1310nm ↑ Upstream

This means a PON connection does not require separate Tx and Rx fibres like a conventional duplex Ethernet SFP.

A current PX20+++ specification explicitly lists BiDi operation over one single-mode fibre core.

SC Fibre Connector

PX20+++ modules commonly use an:

SC optical connector

Some versions specifically use SC/UPC.

Before purchasing, confirm the connector required by the installed OLT and patch cord.

EPON OLT SFP vs Normal Ethernet SFP

You should therefore not install an ordinary 1G Ethernet SFP in place of an EPON PON module simply because both physically fit an SFP cage.

Watch EPON OLT SFP PX20+++ 7dB Video

https://youtu.be/m0ohZokQU84

The PX20+++ optical module provides the PON-side optical interface required by a compatible EPON OLT. Its 1490nm transmitter sends downstream data through the passive optical network, while its 1310nm burst-mode receiver handles upstream signals transmitted by multiple ONUs.

The single-fibre architecture makes EPON particularly efficient for FTTH deployments because one feeder fibre can be divided through passive PLC splitters to serve multiple subscribers. The OLT controls communication between the shared optical interface and registered ONUs.

Selecting a 7dB-class PX20+++ module can provide additional optical headroom compared with lower-output variants, but the network must still be designed according to splitter insertion loss, fibre attenuation, connector losses, splice losses and reserve margin.

EPON OLT SFP for FTTH

PX20+++ modules are commonly used to build Fibre to the Home networks.

Typical architecture:

Internet
↓
Core Router
↓
EPON OLT
↓
PX20+++ 7dB SFP
↓
ODF
↓
Feeder Fibre
↓
PLC Splitter
↓
FAT Box
↓
FTTH Drop Cable
↓
EPON ONU
↓
Customer Router

EPON OLT SFP for ISPs

The module is particularly suitable for:

• Local ISPs

• Estate internet providers

• Apartment networks

• Rural broadband networks

• Campus networks

• Business parks

• WISPs expanding into fibre

• Metropolitan fibre operators

EPON OLT SFP for HIOSO OLTs

HIOSO PX20-series modules are available for compatible HIOSO EPON platforms.

A current Kenyan listing specifically identifies the HIOSO EPON OLT SFP PX20+++ 7dBm as intended for long-reach FTTH and ISP access networks.

Compatibility should still be confirmed against the exact OLT model and firmware.

EPON OLT SFP for HA7304

The HIOSO HA7304 is a four-PON-port EPON OLT.

A current Fiber Optics Kenya listing for the HA7304 identifies:

• 4 PON ports

• Up to 256 ONUs

• Up to 1:64 split per PON

• 1490nm Tx / 1310nm Rx

• Up to 20km transmission

• WEB/SNMP/CLI management

A compatible PX20-series module provides the optical interface for each PON port.

EPON OLT SFP for 1x8 Splitters

A 1x8 splitter divides one PON optical path into eight outputs.

Conceptually:

PX20+++ → 1x8 PLC → 8 Distribution Fibres

Actual subscriber count and reach depend on the complete network design.

EPON OLT SFP for 1x16 Splitters

A 1x16 splitter creates 16 optical outputs.

Compared with 1x8, it introduces additional splitter loss, making optical-budget calculation increasingly important.

EPON OLT SFP for 1x32 Splitters

1x32 is a common FTTH split configuration.

A properly engineered PX20+++ network can be used with 1x32 splitting, subject to:

• Fibre distance

• Splitter insertion loss

• Connector loss

• Splice loss

• ONU sensitivity

• OLT receiver characteristics

Can PX20+++ Support 1x64 Splitting?

Some EPON OLT platforms support up to 1:64 logical/physical splitting per PON port.

For example, the HIOSO HA7304 is specified for a maximum 1:64 split ratio and up to 64 ONUs per PON port.

However:

1:64 support does not mean every 20km route will support 64 subscribers.

Optical loss increases as splitter ratio increases.

Optical Splitter Loss

Typical PLC splitter insertion loss increases with split ratio.

Therefore:

1x4 < 1x8 < 1x16 < 1x32 < 1x64

in terms of optical loss.

A network designer must ensure that the optical power reaching the ONU remains within the ONU's receiver range and that upstream power reaching the OLT remains within the OLT receiver specification.

Optical Power Budget

A simplified calculation is:

Available Optical Budget – Network Losses = Remaining Engineering Margin

Network losses include:

• Fibre attenuation

• PLC splitter loss

• Connectors

• Adapters

• Fusion splices

• Mechanical splices

• Patch cords

• Dirty connectors

Do not select a PX20+++ module based only on distance.

PX20+ vs PX20++ vs PX20+++

These particular power classifications are manufacturer-specific examples.

PX20+++ 7dB vs 8dB

Higher-output versions are also available.

Current Kenyan listings include:

Higher output can provide more flexibility in demanding ODN designs, but excessive optical power and receiver limits must also be considered.

DDM / Digital Diagnostic Monitoring

Many PX20+++ modules support an SFF-8472-compatible digital diagnostic interface.

Depending on the OLT, DDM can provide information about:

• Module temperature

• Supply voltage

• Transmit status

• Receive status

• Optical parameters

This can simplify troubleshooting and maintenance.

Hot-Swappable SFP Design

The PX20+++ uses a small-form-factor pluggable design.

This makes it easier to:

• Install

• Replace

• Upgrade

• Troubleshoot

• Change optical power classes

Always follow the OLT manufacturer's maintenance procedure when replacing an active PON module.

EPON OLT SFP PX20+++ 7dB Price in Kenya

Current Kenyan market examples place the EPON OLT SFP PX20+++ 7dB at approximately:

KES 3,900 – KES 3,999

A current HIOSO PX20+++ 7dBm listing is KES 3,900, while another Kenyan listing for a 1.25G Tx1490/Rx1310nm PX20+ ≥7dB 20km module is KES 3,999.

These are third-party market references and should not be treated as the fixed Fiber Optics Kenya selling price.

EPON OLT SFP Price Comparison in Kenya

What Affects EPON OLT SFP Price?

Price depends on:

• Optical power class

• Manufacturer

• OLT compatibility

• 7dB / 8dB / 9dB output class

• Industrial temperature support

• DDM support

• Connector type

• Warranty

• Quantity ordered

EPON OLT SFP vs GPON OLT SFP

Even though the wavelengths can look similar, EPON and GPON optical modules are not automatically interchangeable.

Recommended Accessories

Frequently Asked Questions About EPON OLT SFP PX20+++ 7dB

What is EPON OLT SFP PX20+++?

It is an optical transceiver designed for the PON port of an EPON OLT.

What is the data rate?

Approximately 1.25Gbps.

What is the maximum transmission distance?

Up to approximately 20km, subject to the optical budget.

What fibre does it use?

Single-mode fibre.

How many fibre cores does it use?

One fibre core.

Is it BiDi?

Yes.

What is the transmit wavelength?

1490nm.

What is the receive wavelength?

1310nm.

What connector does it use?

SC is common.

Is SC/UPC available?

Yes, depending on the module.

What does PX20+++ mean?

It identifies a higher-output PX20 EPON module class. Common supplier specifications associate PX20+++ with ≥7dB.

Is this the 7dB version?

Yes, this page refers specifically to the PX20+++ 7dB model.

Are 8dB versions available?

Yes. Current Kenyan listings include PX20++++ 8dB modules.

Are 9dB versions available?

Yes. Current Kenyan listings include 9dB variants.

Is PX20+++ an ordinary Ethernet SFP?

No. It is designed for an EPON OLT PON interface.

Can I use it in a normal Ethernet switch?

Not as a conventional Ethernet SFP.

Can it work with an EPON OLT?

Yes, provided the OLT supports the module.

Can it work with HIOSO OLTs?

Compatible HIOSO versions are available.

Can it work with an HA7304?

PX20-series modules are used with compatible HA7304 EPON configurations.

Can it work with BDCOM?

Compatible versions exist, but verify coding and OLT support.

Can it work with VSOL?

Compatible versions are marketed, but exact OLT compatibility should be checked.

Can it work with HSGQ?

HSGQ PX20+++ modules are available.

Can it connect directly to an ONU?

The optical network between OLT and ONU normally includes fibre infrastructure and may include PLC splitters.

Can I use a PLC splitter?

Yes.

Can it work with a 1x8 splitter?

Yes, subject to optical-budget calculations.

Can it work with 1x16?

Yes, subject to the optical budget.

Can it work with 1x32?

Yes, where the total ODN loss is within specification.

Can it work with 1x64?

Some EPON platforms support 1:64, but actual reach and subscriber count depend on optical loss.

Does it support DDM?

Many versions do.

Is it hot-pluggable?

Yes.

Can I replace PX20+ with PX20+++?

Potentially, but compatibility and optical power levels must first be checked.

Is higher optical power always better?

No. The correct power class should be selected according to the ODN design and receiver specifications.

Can excessive optical power cause problems?

Yes. Receiver input limits must be respected.

Should I calculate the optical budget?

Yes.

What contributes to optical loss?

Fibre length, PLC splitters, connectors, adapters, patch cords and splices.

Should I test the network with an Optical Power Meter?

Yes.

Should I use an OTDR?

An OTDR is useful for measuring fibre length, attenuation, splice losses and faults.

Is this suitable for FTTH?

Yes.

Is it suitable for FTTB?

Yes.

Is it suitable for FTTO?

Yes.

Is it suitable for ISPs?

Yes. It is specifically useful in EPON ISP access networks.

What is the EPON OLT SFP PX20+++ 7dB price in Kenya?

Current Kenyan examples are approximately KES 3,900–3,999.

How much is the 8dB version?

One current Kenyan HIOSO PX20++++ 8dB listing is approximately KES 4,300.

How much is the 9dB version?

One current Kenyan listing is approximately KES 4,499.

Do you supply PX20+++ 7dB modules?

Yes, subject to stock availability.

Do you supply EPON OLTs?

Yes.

Do you supply EPON ONUs?

Yes.

Do you supply PLC splitters?

Yes.

Do you supply ODFs and FAT boxes?

Yes.

Do you supply Optical Power Meters and OTDRs?

Yes.

Can ISPs order in bulk?

Yes. Bulk supply is suitable for ISPs, fibre contractors, estates, campuses and FTTH operators.

Do you deliver outside Nairobi?

Yes. Fiber Optics Kenya supplies fibre optic networking equipment throughout Kenya.

Why Buy EPON OLT SFP PX20+++ 7dB from Fiber Optics Kenya?

Contact Fiber Optics Kenya

Fiber Optics Kenya
Lyric House, 7th Floor Room S9
Kimathi Street, Nairobi

Phone: +254 704 991 492
Email: info@fibreopticskenya.co.ke

The EPON OLT SFP PX20+++ 7dB is a high-power optical module for EPON FTTH and ISP access networks. Typical models provide a 1.25Gbps optical interface, 1490nm downstream transmission, 1310nm burst-mode upstream reception, single-fibre BiDi operation and distances up to 20km.

Compared with lower-power PX20+ and PX20++ modules, the PX20+++ class provides additional optical output for networks with greater distribution losses. However, splitter ratios, fibre distance, connector losses, splices and engineering margin must still be considered when designing the ODN.

Current Kenyan market examples place the PX20+++ 7dB module at approximately KES 3,900–3,999, while higher-power 8dB and 9dB variants are also available.

Contact Fiber Optics Kenya for current EPON OLT SFP PX20+++ 7dB prices in Kenya, PX20 modules, EPON OLTs, ONUs, PLC splitters, ODFs, FAT boxes, fibre cables, testing equipment, bulk ISP orders and nationwide delivery.
