8 Core FAT Box 1x8 SC/APC in Kenya
KSh 1,300.00
1 available
Continue shopping8 Core FAT Box 1x8 SC/APC in Kenya
The 8 Core FAT Box 1x8 SC/APC is a compact fibre access terminal designed to combine fibre termination, splicing, splitting, protection and subscriber distribution within one organized enclosure. It is particularly suitable for FTTH and GPON networks where one incoming feeder fibre needs to be divided into as many as eight downstream subscriber connections.
A typical loaded 8-core configuration incorporates a 1x8 PLC splitter and eight SC/APC adapter ports. The SC/APC interfaces are usually green, making them easy for technicians to distinguish from blue SC/UPC interfaces. Commercial 8-port FTTH terminal boxes are specifically available with 1x8 PLC splitter capacity and eight green SC/APC connections.
At Fiber Optics Kenya, the 8 Core FAT Box 1x8 SC/APC is suitable for ISPs, fibre installers, telecommunications contractors, residential estates, apartment buildings, offices and commercial FTTH projects. Customers can also source matching SC/APC patch cords, pigtails, fast connectors, drop cables, fibre cleavers, optical power meters, VFLs and other installation accessories.
Key Product Specifications
| Specification | Details |
|---|---|
| Product Name | 8 Core FAT Box 1x8 SC/APC |
| Product Type | Fibre Access Terminal / Fibre Distribution Box |
| Core Capacity | 8 Core |
| Subscriber Capacity | Up to 8 connections |
| Splitter Configuration | 1x8 |
| Splitter Technology | PLC |
| Number of Splitter Inputs | 1 |
| Number of Outputs | 8 |
| Connector Type | SC/APC |
| Connector Colour | Green |
| Fibre Mode | Single Mode |
| Typical Fibre Category | OS2 |
| Typical Fibre Type | G.657A / G.652D depending on splitter |
| Typical Core/Cladding | 9/125 µm |
| Ideal Split per Output | Approx. 12.5% |
| Operating Wavelength | Typically 1260–1650 nm |
| Typical 1x8 Insertion Loss | Around 10.2–10.5 dB |
| Typical PDL | ≤0.2 dB |
| Typical Uniformity | ≤0.8 dB |
| Typical Return Loss | ≥55 dB |
| Typical Directivity | ≥55 dB |
| Splicing Capability | Yes |
| Fibre Storage | Yes |
| Drop Cable Management | Yes |
| Mounting | Wall / pole depending on model |
| Typical Material | ABS / PC+ABS engineering plastic |
| Power Requirement | None |
| Applications | FTTH, GPON, EPON, FTTx |
| Professional Installation | Available |
| Delivery | Available throughout Kenya |
A representative SC/APC 1x8 PLC splitter uses G.657A single-mode fibre, 1260–1650 nm operation, 10.2–10.5 dB insertion loss, 0.2 dB PDL, 0.8 dB uniformity and 55 dB return loss/directivity.
What Is an 8 Core FAT Box 1x8 SC/APC?
An 8 Core FAT Box 1x8 SC/APC combines several FTTH distribution functions within one enclosure.
| Component | Main Function |
|---|---|
| FAT Enclosure | Protects fibre components |
| Feeder Cable Entry | Receives incoming fibre cable |
| Splice Tray | Stores protected fusion splices |
| 1x8 PLC Splitter | Splits one signal into eight |
| 8 SC/APC Adapters | Creates subscriber connection ports |
| Fibre Routing Guides | Organizes fibre paths |
| Drop Cable Ports | Routes subscriber cables |
| Cable Clamps | Secures incoming/outgoing cables |
| Fibre Storage Area | Stores service loops |
| Cover & Locking System | Protects internal components |
Commercial 8-core boxes are available specifically with eight SC/APC adapter positions and 1x8 splitter compatibility.
What Does FAT Mean?
| Term | Meaning |
|---|---|
| FAT | Fiber Access Terminal |
| 8 Core | Eight fibre distribution positions |
| 1x8 | One optical input divided into eight outputs |
| SC | Standard / Subscriber Connector |
| APC | Angled Physical Contact |
| PLC | Planar Lightwave Circuit |
| FTTH | Fibre to the Home |
| GPON | Gigabit Passive Optical Network |
The FAT box becomes the transition point between the distribution fibre network and individual subscriber drop fibres.
How the 1x8 SC/APC FAT Box Works
A feeder fibre enters the FAT box and connects to the input of the internal 1x8 splitter. The splitter then divides the signal across eight outputs.
| Stage | Function |
|---|---|
| Feeder Fibre | Carries upstream optical signal |
| Splitter Input | Receives feeder signal |
| 1x8 PLC Circuit | Divides optical power |
| SC/APC Output 1 | Subscriber 1 |
| SC/APC Output 2 | Subscriber 2 |
| SC/APC Output 3 | Subscriber 3 |
| SC/APC Output 4 | Subscriber 4 |
| SC/APC Output 5 | Subscriber 5 |
| SC/APC Output 6 | Subscriber 6 |
| SC/APC Output 7 | Subscriber 7 |
| SC/APC Output 8 | Subscriber 8 |
A balanced 1x8 PLC splitter provides approximately 12.5% of the incoming optical power to each output in an ideal split, with practical insertion loss commonly around 10.2–10.5 dB.
Typical 1x8 Optical Distribution
| Parameter | Value |
|---|---|
| Optical Inputs | 1 |
| Optical Outputs | 8 |
| Ideal Power per Output | 12.5% |
| Theoretical Split Loss | Approx. 9.03 dB |
| Typical Practical Insertion Loss | 10.2–10.5 dB |
| Maximum Subscriber Connections | Up to 8 |
| Electrical Power Required | None |
The actual optical power reaching a customer also depends on fibre distance, connector losses, fusion splices and any additional splitter stages.
SC/APC Connector Features
| Feature | Benefit |
|---|---|
| Green Housing | Easy APC identification |
| Angled Physical Contact | Reduces optical back reflection |
| SC Push-Pull Design | Easy connection and removal |
| Factory-Terminated Ports | Faster FTTH installation |
| Single-Mode Compatibility | Excellent |
| FTTH Compatibility | Excellent |
| GPON Compatibility | Excellent |
| Low Reflection | Useful for PON links |
| Easy Maintenance | Ports can be cleaned and reconnected |
The green SC/APC interfaces are clearly visible on professional 8-core FAT boxes and FTTH terminals.
Why SC/APC Is Popular for FTTH
SC/APC uses an angled fibre end face to reduce reflected optical energy.
| SC/APC Advantage | Benefit |
|---|---|
| Lower Back Reflection | Better optical signal quality |
| Green Colour Coding | Easy field identification |
| PON Compatibility | Excellent |
| Single-Mode Operation | Excellent |
| FTTH Deployment | Very Common |
| CATV Fibre Networks | Excellent |
| High Return Loss | Suitable for reflection-sensitive links |
Representative 1x8 SC/APC PLC splitters specify return loss of around 55 dB or higher.
Typical PLC Splitter Performance
| Optical Parameter | Typical / Representative Value |
|---|---|
| Splitter Ratio | 1x8 |
| Operating Wavelength | 1260–1650 nm |
| Fibre Mode | Single Mode |
| Connector Type | SC/APC |
| Insertion Loss | 10.2–10.5 dB |
| Loss Uniformity | ≤0.8 dB |
| PDL | ≤0.2 dB |
| Return Loss | ≥55 dB |
| Directivity | ≥55 dB |
| Wavelength Dependent Loss | Around ≤0.3 dB |
| Operating Temperature | Around -40°C to +85°C |
These are representative values from current commercial 1x8 SC/APC splitter specifications.
Why the 1260–1650 nm Range Matters
| Wavelength | Typical Application |
|---|---|
| 1310 nm | PON upstream |
| 1490 nm | GPON downstream |
| 1550 nm | Video / additional optical services |
| 1577 nm | Newer PON technologies |
| 1625 nm | Fibre monitoring and testing |
Current 1x8 PLC splitter products commonly support 1260–1650 nm operation.
Loaded FAT Box vs Empty FAT Box
| Feature | Loaded 1x8 SC/APC FAT Box | Empty FAT Box |
|---|---|---|
| Enclosure | Included | Included |
| 1x8 PLC Splitter | Typically Included | Usually Not Included |
| SC/APC Adapters | Typically Included | Usually Not Included |
| Ready for Subscriber Connections | Yes | Requires Assembly |
| Installation Time | Faster | Longer |
| Configuration Flexibility | Moderate | Excellent |
| On-Site Fibre Work | Reduced | Higher |
| Best Application | Fast FTTH Rollout | Customized Projects |
A loaded 1x8 SC/APC enclosure is therefore particularly attractive for installers who want to reduce the amount of component assembly required on site.
SC/APC FAT Box vs SC/UPC FAT Box
| Feature | SC/APC | SC/UPC |
|---|---|---|
| Typical Port Colour | Green | Blue |
| Polish | Angled Physical Contact | Ultra Physical Contact |
| Back Reflection | Lower | Low |
| FTTH / GPON | Very Common | Used where specified |
| CATV | Excellent | Less preferred |
| Connector Compatibility | APC Only | UPC Only |
| Direct APC-to-UPC Mating | No | No |
The connector type should remain consistent throughout the fibre path.
8 Core FAT Box vs 16 Core FAT Box
| Feature | 8 Core FAT Box | 16 Core FAT Box |
|---|---|---|
| Typical Subscribers | Up to 8 | Up to 16 |
| Common PLC Splitter | 1x8 | 1x16 |
| Physical Size | Smaller | Larger |
| Optical Split Loss | Lower | Higher |
| Small Estate Use | Excellent | Good |
| High-Density Deployment | Moderate | Better |
| Cable Management Complexity | Lower | Higher |
8 Core FAT Box vs Fibre Distribution Box
| Feature | FAT Box | FDB |
|---|---|---|
| Subscriber Access | Primary Purpose | Primary Purpose |
| Fibre Splicing | Yes | Yes |
| PLC Splitter Housing | Common | Common |
| Adapter Installation | Common | Common |
| FTTH Use | Excellent | Excellent |
| Drop Cable Management | Excellent | Excellent |
In many fibre projects, the terms FAT box and FDB overlap because both perform subscriber fibre-distribution functions.
8 Core FAT Box vs ODF
| Feature | 8 Core FAT Box | ODF |
|---|---|---|
| Main Purpose | Local subscriber distribution | Central fibre management |
| Typical Capacity | Small | Medium to Very High |
| 1x8 Splitter Use | Excellent | Possible |
| Subscriber Drop Management | Excellent | Less Direct |
| Wall Mounting | Very Common | Available |
| Rack Mounting | Rare | Very Common |
| Outdoor Versions | Available | Less Common |
| Access Network Use | Excellent | Backbone/Distribution |
Indoor vs Outdoor FAT Box
| Feature | Indoor | Outdoor |
|---|---|---|
| Weather Protection | Basic | Higher |
| Water Resistance | Limited | Required |
| UV Resistance | Less Critical | Important |
| Wall Installation | Common | Common |
| Pole Installation | Less Common | Common on suitable models |
| Sealed Cable Entries | Basic | Important |
| FTTH Use | Excellent | Excellent |
Commercial 8-core SC/APC terminal boxes are available with protective PC+ABS or similar housings for wall-mounted FTTH deployment, though the exact IP rating should always be checked for the specific model supplied.
Typical Internal Components
| Component | Purpose |
|---|---|
| 1x8 PLC Splitter | Divides feeder optical signal |
| 8 SC/APC Adapters | Provides subscriber interfaces |
| Input Pigtail | Connects feeder to splitter |
| Output Fibres | Connect splitter to adapters |
| Splice Tray | Stores fusion joints |
| Fusion Sleeves | Protects splices |
| Cable Clamps | Secures cables |
| Routing Guides | Controls fibre routing |
| Port Labels | Identifies subscriber connections |
| Dust Caps | Protects unused adapters |
Key Benefits of 8 Core FAT Box 1x8 SC/APC
Up to Eight Subscriber Outputs
A single feeder fibre can be distributed to eight subscriber connections.
Integrated 1x8 PLC Splitter
The optical signal is divided passively without switches or powered equipment.
SC/APC Interfaces
Green APC adapters provide low-reflection subscriber connections.
Faster Installation
A loaded FAT box eliminates much of the assembly required with an empty enclosure.
Organized Fibre Management
Splices, splitter fibres, adapters and subscriber drop fibres remain protected and organized.
Compact FTTH Distribution
Eight outputs provide a practical capacity for apartment blocks, residential clusters and small commercial installations.
Passive Operation
Neither the FAT box nor its PLC splitter requires mains power.
Watch 8 Core FAT Box 1x8 SC/APC
Watch on YouTube: https://youtu.be/AeNShmZivYo
The 8 Core FAT Box 1x8 SC/APC provides a convenient distribution point for FTTH networks requiring up to eight downstream fibre connections. Commercial 8-port terminal boxes are available with eight green SC/APC adapter positions and space for a 1x8 PLC splitter, allowing the enclosure to combine splitting, fibre management and subscriber termination within a single compact unit.
The internal 1x8 PLC splitter divides one feeder signal into eight optical paths. A quality SC/APC 1x8 splitter typically operates across 1260–1650 nm and can achieve insertion loss around 10.2–10.5 dB, with low polarization-dependent loss and good output uniformity. These losses should be incorporated into the complete GPON or FTTH optical budget alongside fibre attenuation, splices, adapters and connector losses.
For installers and ISPs, the loaded SC/APC format simplifies subscriber activation because compatible drop fibres and patch cords can connect directly to the green adapter ports. Fiber Optics Kenya can supply the 8 Core FAT Box 1x8 SC/APC together with SC/APC patch cords, pigtails, fast connectors, FTTH drop cables, optical power meters, PON meters, VFLs and fibre installation tools, helping customers source complete fibre distribution solutions.
Applications of 8 Core FAT Box 1x8 SC/APC
1. FTTH Subscriber Distribution
Distribute one incoming feeder fibre to up to eight subscriber connections.
2. GPON Networks
Provide passive distribution between an upstream OLT and downstream ONTs.
3. Residential Estates
Serve small clusters of homes from one fibre distribution point.
4. Apartment Buildings
Provide fibre connections to several apartments or floors.
5. Commercial Buildings
Distribute FTTH connections to offices, tenants or shops.
6. ISP Access Networks
Create standardized subscriber connection points throughout an FTTH rollout.
7. Fibre Distribution Points
Combine splicing, splitting, termination and subscriber connection management.
8. Campus Networks
Distribute single-mode fibre to several downstream locations.
9. CCTV Fibre Infrastructure
Provide organized single-mode optical distribution where appropriate.
10. Telecommunications Networks
Support compact passive subscriber fibre distribution.
Typical FTTH Architecture Using 8 Core FAT Box
| Network Stage | Typical Component |
|---|---|
| Central Equipment | OLT |
| Feeder Network | Single Mode Fibre |
| FAT Input | Feeder Fibre |
| Splitter | 1x8 PLC Splitter |
| Output Interfaces | 8 × SC/APC |
| Subscriber Drop | FTTH Drop Cable |
| Customer Termination | SC/APC |
| Customer Equipment | Compatible ONT / ONU |
Typical Port Allocation
| Port | Subscriber Assignment |
|---|---|
| SC/APC 1 | Subscriber 1 |
| SC/APC 2 | Subscriber 2 |
| SC/APC 3 | Subscriber 3 |
| SC/APC 4 | Subscriber 4 |
| SC/APC 5 | Subscriber 5 |
| SC/APC 6 | Subscriber 6 |
| SC/APC 7 | Subscriber 7 |
| SC/APC 8 | Subscriber 8 |
Optical Budget Considerations
| Loss Source | Include? |
|---|---|
| 1x8 PLC Splitter | Yes |
| Feeder Fibre Attenuation | Yes |
| Distribution Fibre | Yes |
| FTTH Drop Fibre | Yes |
| Fusion Splices | Yes |
| SC/APC Connectors | Yes |
| Adapters | Yes |
| Additional Splitters | Yes |
| Engineering Margin | Yes |
The internal splitter alone may account for roughly 10.2–10.5 dB of insertion loss, so optical power-budget calculation is important.
Installation Considerations
| Installation Factor | Recommendation |
|---|---|
| Connector Type | Maintain SC/APC compatibility |
| Connector Cleaning | Clean before every connection |
| Splitter Loss | Include in optical budget |
| Incoming Cable | Secure firmly |
| Drop Cables | Route through designated outlets |
| Fibre Bend Radius | Avoid tight bends |
| Port Labelling | Clearly label 1–8 |
| Unused Ports | Keep dust caps fitted |
| Splices | Protect with heat-shrink sleeves |
| Testing | Measure optical power at each active port |
Recommended Accessories
| Accessory | Purpose |
|---|---|
| SC/APC Patch Cord | Subscriber/equipment connection |
| SC/APC Pigtail | Fibre termination |
| SC/APC Fast Connector | Field termination |
| SC/APC Adapter | Replacement coupling interface |
| FTTH Drop Cable | Subscriber connection |
| Fusion Splice Sleeve | Protects fibre splice |
| Fibre Cleaver | Precision fibre preparation |
| Fibre Stripper | Removes fibre coating |
| Fusion Splicer | Creates permanent fibre joints |
| SC/APC Cleaner | Cleans connector ferrules |
| Visual Fault Locator | Checks continuity |
| Optical Power Meter | Measures optical signal |
| PON Power Meter | Tests PON optical levels |
| OTDR | Diagnoses fibre faults |
Why Buy 8 Core FAT Box 1x8 SC/APC from Fiber Optics Kenya?
| Why Choose Fiber Optics Kenya? | Customer Benefit |
|---|---|
| 8 Core FAT Boxes | Compact FTTH distribution |
| 1x8 PLC Splitter Configuration | Supports eight branches |
| SC/APC Interfaces | Ideal for compatible PON networks |
| Matching SC/APC Patch Cords | Complete connectivity |
| Pigtails & Fast Connectors | Flexible termination options |
| FTTH Drop Cables | Complete subscriber links |
| Splicing Accessories | Professional installation support |
| Fibre Testing Equipment | Verify network performance |
| Technical Guidance | Help selecting compatible products |
| Bulk Supply | Suitable for ISPs and contractors |
| Competitive Pricing | Cost-effective FTTH deployment |
| Nationwide Delivery | Supply throughout Kenya |
Frequently Asked Questions
What is an 8 Core FAT Box 1x8 SC/APC?
It is a fibre access terminal designed for eight downstream fibre connections, commonly incorporating a 1x8 PLC splitter and eight SC/APC adapter ports.
What does FAT mean?
FAT means Fiber Access Terminal.
What does 8 Core mean?
It refers to approximately eight fibre subscriber connection positions.
What does 1x8 mean?
It means one incoming optical signal is divided into eight downstream signals.
What does SC/APC mean?
SC/APC refers to an SC connector using an Angled Physical Contact fibre end face.
What colour are SC/APC connectors?
They are normally green.
Does the box contain a 1x8 splitter?
A loaded 1x8 SC/APC FAT Box normally includes or is configured around a 1x8 PLC splitter, but exact supplied contents should always be confirmed for the particular model.
How many subscribers can it serve?
It can typically support up to eight downstream subscriber fibre connections, subject to the network architecture and optical power budget.
Is the splitter single mode?
Yes. Typical 1x8 SC/APC PLC splitters are designed for single-mode fibre.
What fibre type is commonly used?
Representative models use G.657A single-mode fibre.
What is the operating wavelength?
Typical PLC splitters operate across approximately 1260–1650 nm.
What is the insertion loss?
Representative 1x8 SC/APC splitters specify around 10.2–10.5 dB insertion loss.
What is the PDL?
Representative models specify approximately ≤0.2 dB polarization-dependent loss.
What is the output uniformity?
A representative 1x8 SC/APC splitter specifies approximately ≤0.8 dB uniformity.
What is the return loss?
Representative SC/APC 1x8 splitters specify approximately ≥55 dB return loss.
Does it require electricity?
No. The FAT enclosure and PLC splitter are passive optical components.
Is it suitable for FTTH?
Yes. Eight-port SC/APC terminal boxes are specifically designed for FTTH subscriber distribution.
Is it suitable for GPON?
Yes. A 1x8 PLC splitter is suitable for GPON networks when the total optical power budget permits.
Can it be used in EPON?
Yes. PLC splitter-based terminal boxes can also be used in compatible EPON networks.
Can it be mounted on a wall?
Yes. Wall mounting is common for 8-core fibre access terminal boxes.
Can it be pole mounted?
Some outdoor models allow pole installation, depending on the mounting hardware and enclosure design.
Can it be installed outdoors?
Yes, if the specific enclosure is designed and rated for outdoor deployment. The exact weatherproof/IP rating should be confirmed before installation.
Does it support fibre splicing?
Yes. FAT boxes commonly provide fibre routing and splice-management areas.
Can I connect SC/UPC patch cords to this FAT box?
No. Use SC/APC connections. UPC and APC end-face geometries should not be directly mated.
What is the difference between SC/APC and SC/UPC FAT boxes?
The SC/APC version uses green angled connectors with lower reflection, while SC/UPC normally uses blue ultra-physical-contact connectors.
What is the difference between this and an empty 8 Core FAT Box?
An empty FAT box requires the installer to add the splitter, adapters and other components, while a loaded 1x8 SC/APC version is already configured for subscriber distribution.
What is the difference between 8 Core and 16 Core FAT boxes?
An 8-core box typically supports eight outputs, while a 16-core box can provide approximately sixteen connections and often accommodates a 1x16 splitter.
Can one subscriber port remain unused?
Yes. Keep unused SC/APC ports protected with dust caps.
Do you supply SC/APC patch cords?
Yes. Fiber Optics Kenya can supply compatible SC/APC single-mode patch cords.
Do you supply SC/APC fast connectors?
Yes. Matching SC/APC fast connectors can be supplied for field termination.
Do you supply FTTH drop cable?
Yes. Compatible indoor and outdoor FTTH drop cables can be supplied.
Do you supply optical power meters and VFLs?
Yes. Fibre testing tools can be supplied for commissioning and troubleshooting.
Do you provide fibre installation and testing?
Yes. Professional fibre installation, fusion splicing, termination and optical testing support is available.
Do you deliver outside Nairobi?
Yes. Fiber Optics Kenya supplies fibre optic products and accessories throughout Kenya.
Contact Fiber Optics Kenya
Fiber Optics Kenya
Lyric House
7th Floor Room S9
Kimathi Street
Nairobi
Phone: +254 704 991 492
Email: info@fibreopticskenya.co.ke
The 8 Core FAT Box 1x8 SC/APC provides a compact and organized solution for splitting and distributing one optical feeder to up to eight FTTH subscriber connections.
Contact Fiber Optics Kenya for competitive pricing, 8 Core SC/APC FAT Boxes, matching FTTH accessories, bulk orders and nationwide delivery across Kenya.
